SM-500 • 7

• Treble Control ±15dB cut/boost (shelving point: 2kHz)

• Transparency Control ±15dB cut/boost (shelving point: 5kHz)

• Variable Graphic Equalizer with ±15dB cut/boost

• Band One: 31Hz to 160Hz

• Band Two: 80Hz to 320Hz

• Band Three: 200Hz to 800Hz

• Band Four: 400Hz to 1.6kHz

• Effects Blend Control

• Dual Concentric (Stereo) Master Volume Control

• Speaker On/Off Switch

• Power On/Off Switch

• Rack Handles

SM-500 REAR PANEL FEATURES

• Balanced XLR Output with select switch for Line or Direct Mode

• XLR ground lift & pad control

• Power Amp Assign Switch (selects Bridge or Stereo mode)

• Side Chain Effects Loop

• Tuner Output

• Two 1/4" jacks per side for Left and Right Stereo Output

• One Speakon

output jack per side for Left and Right Stereo Output

• One Speakon

output jack for Mono/Bridge operation

• (2) Speaker fuses: 3AG, 8 amp, fast-blo

• (1) Line Fuse: 3AG, 7 amp, slo-blo

• AC power cord receptacle

SM-500 SPECIFICATIONS

Note: All measurements were taken with a line voltage of 120VAC. All noise specifications are “unweighted.” All

voltages and watts are "RMS." All measurements taken with tone controls set flat, Aural Enhancer at minimum.

POWER (minimum):

Bridge/Mono Mode

400 Watts @ 8 Ohms

250 Watts @ 16 Ohms

(minimum load = 8 Ohms)

Stereo Mode (per side)
