12-PACK12-PACK
SPECIFICATIONS
Description: 2x12 bass speaker enclosure
Power Handling: 400 watts RMS
Impedance: 8 Ohms
Speaker Complement: Two custom 12-inch SWR drivers
Heavy-Duty Inset Metal Handles, Front Slot Port
Dimensions: 30.5"W x 23.125"H x 20.75"D
Weight: 68 lbs.
CONNECTION AND OPERATION
The 12-Pack can be connected to any musical instrument amplifier that is capable of driving an 8 ohm
load. To connect your amplifier to the 12-Pack, run a high quality speaker cable (18 gauge or heavier)
from your amplifier's speaker output to one of the designated speaker inputs (Speakon or 1/4") on the
12-Pack's input panel.
POWER HANDLING
The power output rating for any amplifier connected to the 12-Pack should not exceed the
enclosure's 400 watt RMS power handling capacity. Please be aware that exceeding the 12-Pack's
power handling capacity can void the SWR warranty if any damage occurs to your loudspeakers due to
overpowering.
FULL-RANGE INPUT AND OUTPUT JACKS
The 12-Pack features four full range input/output jacks (two standard 1/4" and two Speakon) wired in
parallel. If you are running two speaker enclosures in parallel, connect the speaker cable from your
amplifier to either jack marked "IN," and a second cable from either jack labeled "OUT" to the input of
the second speaker enclosure.
16 • BASS SPEAKER ENCLOSURES OWNER’S MANUAL
