4
1.1 To fit the base display simply open
up the clasp and fit around your
bikes handlebars.
1.2 Tighten the screw on the back of
the display using a 3mm Allen key.
Installation
Check your brakes and
gear shifters work as
normal.
!
1.3 Connect the green power cable into
the green cable coming out from
the mount/harness. Find the arrow
on each connector, align and push
togtether intil no colour is visible.
To Next Page
