Page 3 of 9 9/19/2012
2. DIMENSIONS:
2.1 Length: 32.5”
2.2 Width: 26.5”
2.3 Height: 31”
2.4 Weight: 141 lbs
2.5 Housing: Galvanize steel
2.6 Motor: 1.0 HP, 2 Speed
2.7 Power Supply: 115 VAC, 60 Hz, 15 amp
3. OPERATION:
3.1 Electrical Requirements:
3.1.1 The SYCLONE requires a minimum of 115 VAC, 60 Hz, 15 amp, power supply for
normal operation.
3.1.2 The unit requires a heavy duty industrial grade 12-3 cord, in good condition, and
should not exceed 50 ft. in continuous length for proper operation. If more than 50 ft
is needed, please consult with your distributor.
3.1.3 The unit needs to be grounded properly, including the ground pin on the plug. Keep
electrical cords away from water and do not use a damaged cord.
3.2 Unit Set-up:
3.2.1 The unit should be located away from doorways or other make-up air sources.
3.2.2 Place the end of the exhaust port through an opening in the plastic barrier or wall
covering, using duct tape to seal off any opening. Do not exhaust to uncontaminated
or occupied areas.
DO NOT OPERATE THE SYCLONE WITHOUT THE HEPA FITLER INSTALLED!
OPERATING WITHOUT THE HEPA FILTER INSTALLED OR USING NON-APPROVED
POWER CORDS MAY CAUSE DAMAGE TO THE ELECTRICAL SYSTEM OR
MECHANICAL COMPONENTS. FAILURE TO COMPLY WILL VOID
ALL WARRANTIES.
