SycoTec e@syDrive 4624 - Page 4

EN
4
6.5 Terminal 20…27 29
Safe Torque Off – Terminal 20…27 29
6.6 Terminal 30…35 30
Relay 1 and Relay 2 – Terminal 30…35 30
6.7 Terminal 40…59 31
Motor temperature sensor –.Terminal 40...41 31
Frequency output – Terminal 42…43 31
Analog input 0…10 V – Terminal 44…46 32
Analog input 0…20 mA – Terminal 47…48 32
Analog output 0…10 V – Terminal 49 32
Digital PLC input – Terminal 50…51 33
Digital inputs – Terminal 52...59 33
6.8 Terminal 60…63 34
CAN bus connection – Terminal 60…63 34
6.9 Mini USB connector 35
6.10 Micro SD card 35
7.0 Switch-on Sequence 36
8.0 Status Report / Malfunctions / Error Correction 37
8.1 Status Report 37
8.2 Description of LEDs 37
8.3 Warnings 38
8.4 Errors 39
8.0 Operating Software and Programming 40
Warranty Conditions 40
CE Declaration of Conformity 40
