Sylvania SDPF1087 - Product Diagram; Remote Control

4
1. Product Diagram
1.1 Remote Control
1) POWER — Switch On/Off.
2) BGM — Slideshow with background music.
3) MUTE — Press Mute button to silence the voice temporarily.
4) MENU — Enter into Main Menu.
5) — Functional selection button from the bottom to the top cursor.
6) RETURN — Return to upper page.
7) — Functional selection button from right to left cursor.
8) — Functional selection button from left to right cursor.
9) — Functional selection button from the top to the bottom cursor.
10) SETUP — Go to Setup mode.
11) — Press it to Play under stop or pause Status / Press it to Pause on playing
Status.
12) OK — TO Confirm or Switch Pause /Play Function.
13) ZOOM — Change magnification 6 times In the single picture pause mode.
14/15）VOL +/- — Turn up/down the volume.
16）ROTATE — Counterclockwise 90°In the picture pause mode each time.
17) — Move back to previous music or video file.
18) — Move forward to next music or video file.
