LBC-02/IP
TELNET VT-100 EMULATION
DEFAULT KEYBOARD MAPPING:
M1 = F1 (ESC 1)
M2 = F2 (ESC 2)
M3 = F3
(ESC 3)
M4 = F4
(ESC 4)
M5 = TAB (ASCII 9)
ESC = RESET
(ESC R)
LBC-02 KEYPAD SEQUENCES (Make this sequence directly on the LBC-02/IP KeyPad):
ESC . 0 = Go to BOOT mode (In terminal Mode)
ESC
.
1 = Reset TCP/IP connection and Close TCP connection
(In terminal Mode)
ESC . 9 = Show IP Configuration (In terminal Mode)
ESC . H = Cursor position HOME (In terminal Mode)
BARCODE AND TTLIN SUFFIX CONFIGURATION, IF YOU SEND THIS SEQUENCE AT LINE 3 OR MORE :
><A = SUFFIX ASCII 13 (ENTER)
><B = SUFFIX ASCII 9 (TAB)
><C = SUFFIX ASCII 0 (NOTHING)
BARCODE PREFIX CONFIGURATION,
IF YOU SEND THIS SEQUENCE AT LINE 3 OR MORE :
><Fxx = PREFIX ASCII xx (00 to FF) *00 = nothing
TTL OUTPUT, IF YOU SEND THIS SEQUENCE AT LINE 3 OR MORE :
• Output TTL x ON/OFF
><Txy
x = TTL Number 1 to 4
y = E for Enable or D for Disable
Sequence example, set TTL output 2 to ON: ><T2E
• Output TTL x during y seconds
(y = +- 1 second)
><TxTy
x = TTL Number 1 to 4
y = Delay (Two digits)
Sequence example, set TTL output 2 to ON during 4 seconds: ><T2T04
