IP CONFIGURATION WITH BoardConfig SOFTWARE
BOARD CONFIG VERSION 1.1E or more
1. Select the terminal in IP DEVICES LIST (click)
2. Enter the IP and Net Mask of this terminal (Bauds = 57600 Parity = 0 Databits = 0)
3. Check the MODE ACTIVE & KeepAlive
4. Enter the Host IP and (Host Port = 23)
5. Check the Auto Boot
6. Enter your login string
Example: ~~USER^9^PASSWORD^13^
Description: [Pause .5 Secs.] USER [TAB] PASSWORD [ENTER]
7. Push the button: SAVE CONFIG IN TO IP DEVICE
AS/400 WORKSTATION ID:
* BoardConfig software version 1.1L or more supports WORKSTATION ID for AS/400
* This functionality is available on SYMCOD DEVICE VERSION 1.9A and more.
* You can see your product DEVICE VERSION in the BOARD CONFIG software.
MODE PASSIVE
*To open a connection with the LBC-02/IP in mode PASSIVE use the port: 1024
In TERMINAL mode you can:
- Press successively ESC. 0 to return to BOOT mode
- Press successively ESC. 1 to reset TCP Connection
- Press successively ESC. 9 to see the terminal IP configuration
- Press successively ESC. H to Change cursor position: Line 1 Column 1
