BE SURE POWER IS DISCONNECTED PRIOR TO INSTALLATION!
FOLLOW NATIONAL, STATE AND LOCAL CODES.
READ THESE INSTRUCTIONS ENTIRELY BEFORE INSTALLATION.
SymCom’s PumpSaver
®
Plus is a pump monitor designed to protect single-phase pumps from dry-
well, dead-head, jammed impeller, rapid-cycling, overvoltage and undervoltage conditions. The
PumpSaver
®
Plus Model 233P protects 230V, 2 or 3-wire, 1/3 to 3 hp pumps. The PumpSaver
®
Plus
Model 233P-1.5 protects 230V, 2 or 3-wire, 1/3 to 1.5 hp pumps. The PumpSaver
®
Plus Model 111P
protects 115V, 2 or 3-wire, 1/3 to 1 hp pumps. Typical applications include submersible pumps,
centrifugal pumps, circulating pumps, cooling pumps, environmental pumps, residential waterwells,
commercial waterwells, irrigation wells, and golf course and other sprinkler systems.
CONNECTIONS
NOTE: Use with UL/CSA listed overload or impedance protected pumps or motors only.
1. Mount the PumpSaver
®
Plus in a convenient location in or near the pump control box. If the
location is wet or dusty a NEMA 3R, 4, or 12 enclosure should be used. The PumpSaver
®
Plus
must be protected by a fuse or circuit breaker (30A RK5 fuse or 30A inverse time breaker max).
2. Connect one line from the fused disconnect to the L1 IN terminal of the PumpSaver
®
Plus. Run
a wire from the L1 OUT terminal to the other in-line controls such as pressure or float switches.
3. Connect the other line from the fused disconnect (ungrounded fused conductor) to the L2 IN
terminal of the PumpSaver
®
Plus. Run a wire from the L2 OUT terminal to the other in-line
controls such as pressure or float switches (see Figure 1).
4. Refer to the appropriate wiring diagram for your specific application:
• Typical wiring diagram – Figure 1
• Standard 3-wire control box – Figure 2
• Deluxe control box – Figure 3
• 2-Wire pump direct feed – Figure 4
*** WARNING ***
PROPER OPERATION REQUIRES FIELD CALIBRATION
