Arm unit (left)
Back pad
seat
To remove the arm unit
1. Recline the backrest and open the fastner (①) holding arm unit and backrest.
2. Slide the arm unit towards the backrest, push downwards the stopper that is in
between the arm unit and seat (②) and release the lock.
3. Move the arm unit towards the legs part, push the stopper (③) downwards and release
the lock.
4. Lift and remove the arm unit.
Stopper（②,③）
Press this area
with your fingers
and unlock it.
①
③
②
The pillow is fixed to the backrest
with velcro tape.
Velcro tape
Adjust the back pad for your preference.
Cap Back pad can be used as heater.
Refer to "Position the back pad (heater part)" for more details. (P49)
Method to remove the pillow and adjustment of back pad
If you want to attach the back pad
firmly, fix the packrest and back
pad with fastener.
Center of back pad is removable. You can
feel stronger massage when you remove it.
Velcro tape
(Back side)
fastener
(Back side)
【Rear view】
Back pad
(Center part)
Raise the
fastener
on the back of the back pad.
Remove the velcro on the back of the back pad.
14
fastener
To Next Page
