Synectix ATT 2000 - Connection Diagram

5
Connection Diagram
Music In
Volume
Control
Analog
Line in
Overflow
(optional)
Power Supply
12 V AC
PBX
Route all incoming
calls to ATT 2000
Connect
ATT 2000
to Analog
extensions
ATT 2000
Connection Diagram
Wall
Adaptor
