7 Chapter 2: Hardware Setup
b Slide the 2.5" Disk Holder into the hard drive bay, and push it all the way until the hard disk is connected
to the SATA connector. Secure the Disk Holder with the provided screws.
3 Replace the upper case, and tighten the screws on the back panel.
Start up your DiskStation
1 Connect the AC adapter to the power port of DiskStation. Connect one end of the AC power cord to the AC
power adapter, and the other to the power outlet.
2 Use the LAN cable to connect DiskStation to your switch/router/hub.
3 Press and hold the power button to turn on your DiskStation.
Your DiskStation is now online and detectable from a network computer.
