Se i problemi non possono essere risolti per mezzo di quanto indicato in tabella, essi
potrebbero essere causati da disfunzioni dei circuiti interni; in questo caso, scollegare
immediatamente in cavo di alimentazione e rivolgersi al proprio rivenditore od ad un
centro assistenza autorizzato Synthesis.
La ditta Synthesis declina ogni responsabilità per danni diretti o indiretti provocati dall’i-
nosservanza delle prescrizioni di installazione, uso e manutenzione dettagliate nel presente
manuale.
Le specifiche descritte in questo manuale possono essere soggette a modifiche senza
preavviso.
SINTOMO:
Accendendo l’interrut-
tore di rete l’unità non
si accende
Non viene prodotto
nessun suono dagli
altoparlanti
CAUSA:
La presa di rete non è
attiva
- I collegamenti dei cavi
ingresso sono incomple-
ti
- I collegamenti dei cavi
di potenza (verso i dif-
fusori) sono incompleti
- Il volume è impostato
al minimo
- La sorgente collegata
non è nella condizione
di lettura
- E’ stato selezionato un
canale differente da
quello in funzione
SOLUZIONE:
- Accertarsi che i colle-
gamenti siano stati effet-
tuati in modo corretto
- Accertarsi che i colle-
gamenti siano stati effet-
tuati in modo corretto
- Accertarsi che i colle-
gamenti siano stati effet-
tuati in modo corretto
- Controllare il livello
del volume e il mute
- Controllare che sia in
play e riproduca corret-
tamente
- Accertarsi che il com-
mutatore sia nella posi-
zione corretta di selezio-
ne
RISOLUZIONE DEI PROBLEMI It is good to keep in mind the following:
* Do not insert objects under the unit
* Do not block the ventilation slots under
the unit
* Leave at least 30 cm free all around the
unit
CONNECTIONS AND CONTROLS
Rear panel
1) RIGHT SPEAKER output
Pair of power outputs with screw terminals.
The red terminal must be connected to the
positive terminal of the speaker, the black to
the negative. Be careful not to short-circuit
the terminals to avoid damage to the device.
2) S/PDIF Input
Electric type digital audio input, connect
only to a digital source with dedicated out-
put such as CD or DVD player. Support
PCM 32-192KHz, 16-24bit stereo formats.
3) USB Input
USB input, this allows you to use the ampli-
fier as a high quality sound card.
Compatible with Windows XP or newer and
Mac OS 9.1 or newer. Supports audio data
up to 16bit 48KHz stereo.
4-5-6-7) Line Inputs
Unbalanced line input, RCA type, selec-
table using the homonymous button on the
front of the device. Any source with a rated
voltage level higher than 100mV can be
connected to it.
8) PRE OUT connection
Unbalanced variable line output, RCA type.
The maximum gain is approximately 2
times in voltage. It is possible to connect
another amplifier or an active subwoofer.
9) LEFT SPEAKER output
Pair of power outputs with screw terminals.
The red terminal must be connected to the
positive terminal of the speaker, the black to
the negative. Be careful not to short-circuit
the terminals to avoid damage to the device.
10) Power inlet with fuse and switch
It is an IEC standard built-in tray, into
which any cord meeting the same standard
can be connected, as long as it has a capac-
ity of at least 10A. Incorporates the fuse
that protects the electrical circuits. In the
event of a burn for no apparent reason, do
not replace it, but take the appliance to a
service center.
The main switch allows you to completely
turn off the appliance when you plan not to
use it for a long time.
