Installation
Carefully follow the instructions in order not to cause mal-function, damage to the
equipment or humans. Incorrect installation will void the warranty and repairs will
consequently be invoiced according to current scale charges.
All connections are shown on the figures at the fold-out page at the back of this manual.
After all connections have been made installation is completed by switching on the mains
supply. Finally should the Service Pin be activated, however, prior to pressing the Service Pin
make sure the S111SX Node Manager is running and connected to the LON
®
network.
Please note, that it is of outmost importance to keep track of the order in which the various
System X units are activated e.g. by carefully noting the exact time the Service Pin is
activated. This information is crucial when identification and configuration of each unit is
carried out later using the S111SX Node Manager.
Unpacking the unit
Check that the carton box contains the following items:
Ÿ A Matrix X of the correct type (M3216AX, M3216XX, M3208AX or M1608AX).
Ÿ A connector/mounting kit, consisting of:
2 pcs. rack mounting ears.
2 pcs. 9-pin D-SUB connectors.
1 pc. LON
®
connector and cable clamp.
Various screws and washers.
Ÿ Installation manual (this manual).
Carefully check for any sign of damage. Any such damage or parts missing should be
reported to your supplier prior to installation.
Mains installation
The Matrix X must be used with a 3-wire mains connection (2W+PE @ min. 0,75 mm2,
PE=yellow/green, N=blue).
The unit adapts itself to the actual mains voltage; no adjustments are needed.
WARNING: If permanently connected to mains, a readily accessible
disconnect device (mains switch) shall be incorporated in the building
installation wiring.
If pluggable connection to mains has been made, the socket-outlet shall
be present near the equipment and shall be easily accessible.
Mains connection requires installation by an instructed person.
The unit is designed for continous operation.
Mains fuse
A replaceable fuse is located at the power supply board.
Ÿ Designator: F1
Ÿ Rating: F2,5AH, 250V
2850-00002 Page3
