6Commissioning
6.1Beforestartingthesystem
Whentheinstallationisnished,checkthat:
•Theunitisinstalledinaccordancewiththeinstallationinstructions
•Theunitiscorrectlywired
•Mufersareinstalledandthattheductsystemiscorrectlyconnectedtotheunit
•Outdoorairintakeispositionedwithsufcientdistancetopollutionsources(kitchenventilatorexhaust,
centralvacuumsystemexhaustorsimilar)
•Allexternalequipmentareconnected
•Thefollowingdataisavailable:
•Intendedconguration,forexampletemperaturecontrolfunctions,fancontrol,externalcontrol
functionsetc.
•Howtheunitissupposedtooperateaccordingtoaweeklyschedule(normalandreducedspeed)
6.2Initialsetupoftheunit
Ontherststart-up,thecontrollerwillstartaspecialprogramforsettinglanguage,supplyairtemp
setpoint,Time&dateandweekschedulefornormalspeed.Usethe“OK”buttontomovebetween
changeableparametersandtheUP/DOWNarrowstoseethedisplayedalternatives.Conrmbypressing
“OK”oncemore.MoveondowninthemenustructurebyuseoftheUP/DOWNarrows.
Thefollowingwillbedisplayed:
1
Selectlanguagebypressing“OK”andthenmove
betweenthealternativeswiththeUP/DOWN
buttons.Conrmbypressing“OK”.Movetothe
nextlevelbypressingthe“DOWN”button.
ChooseLanguage
English
2
Showstheactualextractairtemperature
Setthesupplyairsetpoint.Defaultis18°C(logon
toservicelevelneeded,code2222,tochange
defaultsetting)
Extractairtemp
Actual:....ºC
Setp.:18ºC
3
Checkandmakesurethatcorrecttimeanddateis
displayed,ifnotchangethesettings
Time:12.46
Date:2010–03–12
Weekday:Friday
4
Settheweekscheduleforhowit’sintendedforthe
unittooperateatnormalspeedduringMondayto
Friday.It’spossibletoset2periodsperday.
Normalspeed
Monday→Friday
Per1:07:00–16:00
Per2:00:00–00:00
