5.6.4TA2000-4500HW

Connectionblock,besidethetransformer,marked160V,240V,320Vand400Vfor400V3~(90V,140V,

185V,230Vfor230V3~)isusedtosetthefanspeed.

Defaultsettingsforhighfanspeedareonterminalpost400V(230V)andlowfanspeedonterminalpost

240V(140V).Whenreconnectingtoanotherfanspeedboththecablesforhigh/lowfanspeedmustbe

moved.E.g.toreducethehighfanspeedonestepthecablesconnectedtothetwoterminalpostsmarked

400V(230V)aretobemovedtothetwoterminalpostsmarked320V(185V).

*=Highfanspeed

**=Highfanspeed400V

***=Highfanspeed230V

TA450-4500Installationinstructions

132615
