8.3Installation

Findanappropriateplacetoinstallthecontrolpanel.Maximumlengthbetweencontrolpaneland

unitis100m.

Ifneeded,drilltwoholesinthewalltohangthecontrolpanel(centertocenter:60mm)(pos.1,gure13).

Fig.13Controlpanelwireconnections

PositionDescription

1Mountingholes

Connectionblock

Connectiontobrowncable

Connectiontoyellowcable

Connectiontowhitecable

Connectiontoblackcable

TA450-4500Installationinstructions

132615

SystemairSverigeAB
