Operation
|
13
6.1.1.7 Humidity control
Setpoints and settings for dehumidification and humidification
6.1.2 Flow chart
Flow diagram
2020–10–22
199 Pa
198 Pa
18 000 m³/h
18 000 m³/h
100 %
54 Pa
34 Pa
22,1 °C
22,1 °C
-6,8 °C
-12,2 °C
71 %
74 %
16,7 °C
21,8 °C
19,9 °C
25 % RH71 % RH
32 % RH
84 %
h
Open
Open
0 %
OFF
42 %
ON
Dynamic flow chart of current configured air handling unit. Active sensors and components are visible
with values shown in real time. When pressing on values or items marked in blue you will be forwarded
to related settings and/or overview page.
6.1.3 Language
Settings of language.
• To synchronize NaviPad with all connected air handling units, go to system dashboard by pressing the
NaviPad button. Press
and , choose language.
• Using
in selected air handling units homepage via NaviPad or computer will only change language
in the selected air handling unit.
