6.1.5 Configuration
• System settings
• Configuration wizard (Example 4)
• Function configuration (Example 5)
• I/O allocation settings
• Alarm configuration (Example 6)
• PID controllers
The configuration wizard is a menu that simplify the procedure to Activate and Configure common accessories and
functions and Allocate it’s in- and outputs. The wizard makes necessary configurations automatically and guide the user
through limited options.
Example 4: Configuration wizard
Configuration > Configuration wizard
2020–10–22
Set up pressure control
>
Set up cooler
>
Set up changeover
>
Exit to configuration menu > Complete configuration wizard >
If the configuration wizard does not cover the desired accessory or function it can still be configured via the configura-
tion menu.
Example 5: Function configuration
Configuration > Functions > Function activation
2020–10–22
Fan compensation curves
Yes
Support control
No
CO2 Control
No
To activate a function go to Function activation. Choose function to activate and set Yes in the following pop-up
menu. Values for the activated function are now visible and can be adjusted in Data Settings.
If required, allocate in- and outputs in I/O allocation settings.
