SystemAir Topvex Series Installation Manual

Topvex Series
VAV installation Kit
Systemair Inc.
4
1 Access rights
Go to Access Rights by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
Temperature
Air Control
Time settings
→Access Rights
2 Log on
Choose Log on. Select by pressing the RIGHT
arrow button.
→Log on
Log o
Change password
3 Password
Enter password 1111 by pressing OK followed by
the UP/DOWN arrow buttons. Select next digit by
pressing the RIGHT arrow button. Press OK when
all 4 digits have been entered.
Go back 2 steps using the LEFT arrow button.
Log on
Enter password xxxx
Actual level: None
4 Conguration menu
Go to Conguration by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
Man/auto
Settings
→Conguration
Access Rights
5 Inputs/Outputs
Go to Inputs/Outputs by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
→Inputs/Outputs
Control function
Fan control
Extra Sequence Y4
6 Analog input exp3
Go to AI exp3 by using the UP/DOWN arrow
buttons. Select by pressing the RIGHT arrow
button.
*If AI exp3 does not appear in this menu, go
back 1 step using the LEFT arrow button and
proceed to step 8.
Topvex ####
YYYY-MM-DD HH:MM
SYSTEMI: STOPPED
SP: ACT: °F ↓

SystemAir Topvex Series Specifications

General

Filter Class	F7
Supply Voltage	230V/400V
Frequency	50 Hz
Dimensions	Varies depending on model. Refer to specific model datasheet.
Weight	Varies depending on model. Refer to specific model datasheet.
