Mainmenuitem
Sub-menuitem1Sub-menuitem2
Explanations
Exhaustair
temp
Actual:ºC
Actualexhaustairtemperature.
Efficiency
exch.
Actual:%
Output
exchanger
Actual:100%
Actualheatrecoveryefciency.
Thefunctioncalculatesthe
heatexchangerstemperature
efciencyin%whentheoutput
signaltotheexchangeris
higherthan5%andtheoutdoor
temperatureislowerthan10°
C.
Whenthecontrolsignalis
lowerthan5%ortheoutdoor
temperatureishigherthan10°
Cthedisplaywillshow0%.
Statusoftheexchangeroutput.
→AirControl
Thismenuoptionbecomes
visibleiftheunitiscongured
for"Flowcontrol"or"Pressure
control".
Flowcontrol
SAF
Actual:m³/h
Setp.:m³/h
Airowforthesupplyairfan
(constantairowcontrol).
Onlyvisibleiftheunitis
conguredforFlowcontrol.
Flowcontrol
SAF
Setp1/1:1100
m³/h
Setp1/2:550
m³/h
Setthenormal(1/1)and
reduced(1/2)airowforthe
supplyairfan.
Outdoor
comp.Setp.1
–20°C=10m³/h
0°C=0m³/h
Act.Comp:0
m³/h
SettheSAFairow
compensationforthesettable
outdoortemperature.The
outdoorcompensationislinear
andissetusingtwoparameter
pairswhichgivethevalueofthe
compensationattwodifferent
outdoortemperatures.The
compensationcanbepositive
ornegative.
Showstheactualairow
compensation.
Flowcontrol
EAF
Actual:+INF
m³/h
Setp.:m³/h
Airowfortheextractairfan
(constantairowcontrol).
Onlyvisibleiftheunitis
conguredforFlowcontrol.
TopvexSR/TR03,SR/TR04,SR/TR06OperationandMaintenanceInstructions
206902
12
SystemairAB
