SystemAir Topvex TR03

2ProductDescription
2.1InternalcomponentsTopvexSR03–06
Fig.1Internalcomponentswithairconnectionssymbols(Drawnasarighthand
unit)
PositionDescription
Symbol
A
Connectionsupplyair
B
Connectionexhaustair
CConnectionoutdoorair
D
Connectionextractair
1
Fansupplyair
2Fanextractair
3
Filtersupplyair
4Filterextractair
5
Heatexchanger
6Rotormotor
7
Rotationguard(sensor)
8
Extradrivingbelt
9
Pressuretransmitterfans
1
10
PressureguardFilters
11
Temp.sensoroutdoorair
12
Electricalre-heaterbattery
2
13Electricalconnectionbox
1.OnlyvalidforunitswithConstantAirVolumecontrol(CAV)
2.Onlyvalidforunitswithelectricalre-heaterbattery
