Outdoor comp. setp.
-20 °C = 0.0 m³/h
10 °C = 0.0 m³/h
A
ct. Comp: 0.0 m³/h
Flow control EAF Pressure control EAF
Actual : 0.0 m³/h Actual : 0.0 Pa
Setp. : 0.0 m³/h Setp. : 0.0 Pa
Flow control EAF
Setp 1/1 : 0000.0 m³/h
Setp 1/2 : 0000.0 m³/h
Outdoor comp. setp.
-20 °C = 0.0 m³/h
10 °C = 0.0 m³/h
A
ct. Comp: 0.0 m³/h
Input/Output
Analogue inputs
Digital inputs
Universal inputs
Analogue outputs
Digital outputs
Time Settings
Time/Date Time: 16:03
Date: 05:10:21
Weekday: Wednesday
Timer Normal Speed Normal Speed
Monday
Per 1: 00:00- 00:00
Per 2: 00:00- 00:00
Normal Speed
Holiday
Per 1: 00:00- 00:00
Per 2: 00:00- 00:00
Set the time when the unit should run on Normal fan speed during Holidays. It is possible to set two Periods
for each Holiday.
N.B. For continuous running set 00:00-24:00.
(see Time Settings/Holidays to set the date of Holidays).
Show the configuration of the Inputs and Outputs.
Show the actual values of the Analog Inputs and Outputs.
Show the status of the Digital Inputs and Outputs.
Set the Time: h : m
Set the Date: year : month : day
Set the Weekday.
Set the time when the unit should run on Normal fan speed. It is possible to set two Periods for each weekday.
Choose weekday with arrow up and down buttons.
N.B. For continuous running set 00:00-24:00.
Normal fan speed have higher priority then Reduced fan speed.
Set the outdoor compensation for the flow/pressure regarding to the outdoor temp
Set maximum compensation.
Set when comp. should start.
Show actual com
p
ensation.
Set the desired flow for full speed and half speed
If VAV control is chosen, set the desired pressure for full speed and half speed.
Set the outdoor compensation for the flow/pressure regarding to the outdoor temp
Set maximum compensation.
Set when comp. should start.
Show actual com
p
ensation.
or
Used when the unit is configured for constant flow or constant pressure control.
Show Actual EAF flow or pressure
Show Set
p
oint of EAF flow or
p
ressure.
