Page 60
Technical data
(*) The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider: the rating, the maximum
working temperature in the room, the type of insulation and the cable laying, the maximum length of the power supply line.
VLS/VLH/VLC/VLR HSE BLN 524 604 704 804 904 1004 1104 1204
Rated voltage V/ph/Hz 400 (±10%) /1/50
Max absorbed power kW 61,2 71,4 82,6 98,2 107,6 114,4 132,4 150,4
Rated current A 88,2 100,3 112,3 120,3 142,4 160,4 172,4 184,4
Max current FLA A 148,2 156,3 186,3 172,3 193,4 210,4 239,4 268,4
Max start-up current LRA A 271 280 350 357 378 434 486 515
External fuses A 200 200 250 250 250 250 315 315
Max cable section (*) mm
2
3x95 3x95 3x120 3x120 3x120 3x120 3x185 3x185
Exchanger Resistance
Rated voltage V/ph/Hz 230 (±10%) /1/50
Max absorbed power kW 130
VLS/VLH/VLC/VLR HSE LN 524 604 704 804 904 1004 1104 1204
Rated voltage V/ph/Hz 400 (±10%) /1/50
Max absorbed power kW 61,2 71,4 82,6 98,2 107,6 114,4 132,4 150,4
Rated current A 88,2 100,3 112,3 120,3 142,4 160,4 172,4 184,4
Max current FLA A 148,2 156,3 186,3 172,3 193,4 210,4 239,4 268,4
Max start-up current LRA A 271 280 350 357 378 434 486 515
External fuses A 200 200 250 250 250 250 315 315
Max cable section (*) mm² 3x95 3x95 3x120 3x120 3x120 3x120 3x185 3x185
Exchanger Resistance
Rated voltage V/ph/Hz 230 (±10%) /1/50
Max absorbed power kW 130
VLS/VLH/VLC/VLR HSE ELN 524 604 704 804 904 1004 1104 1204
Rated voltage V/ph/Hz 400 (±10%) /1/50
Max absorbed power kW 61,2 71,4 82,6 98,2 107,6 114,4 132,4 150,4
Rated current A 88,2 100,3 112,3 120,3 142,4 160,4 172,4 184,4
Max current FLA A 148,2 156,3 186,3 172,3 193,4 210,4 239,4 268,4
Max start-up current LRA A 271 280 350 357 378 434 486 515
External fuses A 200 200 250 250 250 250 315 315
Max cable section (*) mm² 3x95 3x95 3x120 3x120 3x120 3x120 3x185 3x185
Exchanger Resistance
Rated voltage V/ph/Hz 230 (±10%) /1/50
Max absorbed power kW 130
VLS-GB.indd 60 17-06-2009 15:56:47
