All the pictures in this manual are for explanation purpose only. They may be slightly different from the air
conditioner you purchased(depend on model). The actual shape shall prevail.
NOTE
This air conditioner comprises an indoor unit, outdoor
unit, and a connection pipe.
Outdoor unit
Air outlet
1
2
3
4
Air inlet
Fixing support
Refrigerant pipe connector
1
2
3
4
Fig.1
Indoor unit
5
5
Connection pipe
