24 Systematics , Inc. 1025 Saunders Lane West Chester, PA. 19380
OPTIONS
TIGIT2
MHG7
ONE POUND SPOOL GUN
FOR ALUMINUM MIG WELDING
WITH SYSTEMATICS
MIG COMBINATION UNITS
(MP140, MP175 & MP250)
The MHG7 (Motorized Hand Gun System) is a compact, light-in-weight,
easy to operate MIG welding system designed for aluminum welding. It
will feed .030", .035" or 3/64" diameter wire from 4 inch spools. The
standard cable is 25 feet in length. 35 foot and 50 foot cables are optional.
The wire speed control knob is in the gun handle.
With the following options, the MHG7 can be used to weld steel or
stainless steel (.030" - .035" diameter wire sizes).
HG-160K Knurled Drive Roll - for .030" - .035" steel wire
M5-T30 Contact Tip - for .030" steel wire
or M5-T35 Contact Tip - for .035" steel wire
SPECIFICATIONS
Part Number ....................... MHG7
Gun Rating ......................... 200 Amps @ 100% duty cycle
250 Amps @ 60% duty cycle
Wire Feed Speed Range..... 50 to 650 inches per minute
Cooling Method ................. Air (gas)
MHG7 SYSTEM COMPONENTS
1 each MHG-7 Spool Gun
1 each HGC5-25 Hand Gun Cable Assembly
with fittings - 25 foot length
7 (total) MG-T series Contact Tip (1 installed in gun)
2 - .030 (MG-T30)
3 - .035 (MG-T35)
2 - 3/64 (MG-T364)
1 each M35-NA62 Nozzle Assembly
(installed on gun)
1 each M35-D Gas Diffuser
(installed on gun)
CONTENTS OF TIGIT2
1 each TIG Torch with built-in valve
1 each Locking Electric Switch with 14 foot cord
(installed on torch)
1 each 12-1/2 foot Power Cable with Connector
(installed on torch)
1 each 15 foot Gas Hose with fitting (installed on torch)
3 each 3C332 Collet - for 3/32" tungsten
3 each 3C418 Collet - for 1/8" tungsten
2 each 3CB332 Collet Body - for 3/32" tungsten
2 each 3CB418 Collet Body - for 1/8" tungsten
2 each 3A6 Gas Cup - 3/8" orifice
6 each 3A7 Gas Cup - 7/16" orifice
2 each 3A8 Gas Cup - 1/2" orifice
1 each 300L Long Backcap
3 each 3/32" X 3" Tungsten Electrode
3 each 1/8" X 3" Tungsten Electrode
NOW! TIG WELD WITH YOUR
SYSTEMATICS MIG WELDING MACHINE
(MP140, MP175 & MP250)
The TIG Welding Process is used to produce the highest quality,
porosity-free welds. The TIGIT2 adds TIG Welding capabilities to your
Systematics MIG Welder.
The TIGIT2 is designed for Tungsten-Inert Gas (TIG) welding with Direct
Current, Straight Polarity (DCSP) on steel, stainless steel, chrome-moly,
copper or cast iron (12 Gauge (.105") minimum plate thickness).
THE TIGIT2 WILL NOT WELD ALUMINUM.
The TIGIT2 consists of a 200 amp, gas cooled TIG torch with built-in gas
control valve and remote on-off switch, 12-1/2 or 25 foot cable assembly
and accessories required for putting the unit into service.
SPECIFICATIONS
Part Number............... TIGIT2-12 (12-1/2' cable)
TIGIT2-25 (25' cable)
Torch Rating .............. 200 Amps, DCSP
Duty Cycle ................. 100% (reduce duty cycle when
operating over 200 amps.)
Cooling Method ......... Gas
Shielding Gas
Control Method...... Gas Valve on Torch
Welding Current
On-Off Control ...... Locking Switch on Torch
