T.I.P. SPF 370 F User Manual

2
Notes and instructions with the following symbols require particular attention:
Any non-observance of these instructions involves the danger of bodily harm to peo-
ple and/or damage to property.
Any non-
observance of this instruction bears the risk of an electrical shock which may
cause damage to persons or property.
Check the product for transport damage. In case of damage, the retailer must immediately - be in-
formed - but not later than the date of purchase within 8 days.
2. Technical data
Model
SPF 180
SPF 250 F
SPF 370 F
Mains voltage / frequency
220
-
240 V~
/
50 Hz
220
-
240 V~
/
50 Hz
220
-
240 V~
/
50 Hz
Performance P1 / P2
250 Watt / 180 Watt
400 Watt / 250 Watt
550 Watt / 370
Watt
Protection class
IPX5
IPX5
IPX5
Flow rate through sand filter
4.500 l/h
6.000 l/h
7.000 l/h
Max. Flowrate pump (Q
max
)
1)
7.900 l/h
10.000 l/h
13.200 l/h
Max. pressure
0,6 bar
1,0 bar
1,2 bar
Suction port / pressure port
45,48 mm (1½“ fem
a
le)
45
,48 mm (1½“
female
)
45,48 mm (1½“
female
)
Hose connector
32 mm (1¼“),
38 mm (1½“)
32 mm (1¼“),
38 mm (1½")
32 mm (1¼“),
38 mm (1½")
Max. fluid temperature (T
max
)
40° C 40° C 40° C
Min. fluid temperature (T
min
)
5° C 5° C 5° C
Grain size of quartz sand
0,5
to
0,8 mm
0,7
to
1,2 mm
0,5
to
0,8 mm und 0,7
to
1,2 mm
0,5
to
0,8 mm
0,7
to
1,2 mm
Sand filling quantity
2)
13 kg
13 kg
25 kg
Length of power cord
1,9 m
1,9 m
1,9 m
Type of power cord
H07RN
-
F 3 G 1,0 mm²
H07RN
-
F 3 G 1,0 mm²
H07RN
-
F 3 G 1,0 mm²
Weight of pump
4 kg
5 kg
5,5 kg
Dimension of filter set
50 x 35 x 64 cm
50 x 50 x 64 cm
50 x 50 x 68 cm
Total weight of filter set
8 kg
10,8 kg
12,8 kg
Article No.
30307
30308
30309
1)
The values were determined with free, unreduced in- and outlet.
2)
Quartz sand not included
3. Position and function
The pool filter set should be placed on a level concrete slab, very firm ground, or equivalent approxi-
mately 2 to 3 m from the pool edge. Ensure that the ground will not subside, preventing any strain
from the attached plumbing. Protect the set from splash water and humidity. It should not be placed in
an earth hole or directly on the grass ground.
Make sure, the inlet of the pump is placed at least 30 cm under the water level of the swimming pool.
Please note the pump shall be placed on a well-ventilated and dry location, which is protected
against floating and splash water and easy to reach for maintenance. The pump shall not be placed
into a too small chamber or compartment in order to avoid overheating.
Make sure that all electric parts of the pump do not get in touch with water. Dangerous!
The pump is not suited to discharge saltwater, feces, inflammable, etching, explosive or other
hazardous liquids. Please observe the max. Temperature of the liquids to be discharged stat-
ed in the technical data.
Function of the sand filter set
I
ncoming water from the piping system is automatically directed by the 4 position valve to the top of
the filter bed. As the water is pumped through the filter sand, dirt and debris are trapped by the filter
17
