19
1 - 2 WARNING. Foot could be cut away! Do not remove or open guards before the machine has stop-
ped rotating. The tractor engine must be stopped, the ignition key removed and the hand brake
applied.
3 WARNING. Your body could be drawn into the machine! During all work with the rotor the tractor
engine must be stopped, the ignition key removed and the hand brake applied.
4 WARNING. Your body could be crushed! Do not work under the machine unless the cylinders are
equipped with safety devices, see page 49. The tractor engine must be stopped, the ignition key
removed and the hand brake applied.
5 WARNING. Fingers or hand could be crushed! Notice the danger of crushing at springs when the
machine is raised.
6 WARNING. Release of accumulated energy! Never try to dismantle the balance spring. It is pre-
tightened to 300 - 400 kg. The spring must be replaced as a joint unit, - see page 71.
Models 4024 - 4028 - 4032 - 4036:
7 WARNING. Be careful! The drawbar cylinder chain must always be fitted during transport.
