Operator´s manual BIO bale processor B4000
Technical specifications
Valid for standard equipped machine with wheel size 500/50-17"
Description Data
Dimensions
Total length ........................................................................... 4500 mm
Width .................................................................................... 2800 mm
Height ................................................................................... 2300 mm
Weight ......................................................................................... 3250 kg
Wheel dimension
Regular................................................................................. 500/50-17"
Optional ................................................................................ 500/45-22.5"
Optional ................................................................................ 600/40-22.5"
Tractor requirements
Hydraulic hitch/tractor drawbar ............................................ Ø52/Ø
Oil flow required (free return) ............................................... 35 l/min
Oil pressure for ring speed 50 rpm....................................... min. 190 bar
PTO connection ................................................................... 6 splines/540 rpm
Electric power supply ........................................................... 12V
Pick-up
Working width ....................................................................... 2100 mm
Number of tine rows ............................................................. 5
Support wheels .................................................................... adjustable 12 positions
Cutter unit
Number of knives ................................................................. 14
Knife distance ....................................................................... 70 mm
Foreign body protection ....................................................... Spring on every blade
Bale chamber
Diameter............................................................................... 1250 mm
Width .................................................................................... 1220 mm
Number of rollers.................................................................. 18
Roller diameter ..................................................................... 190 mm
Low friction plates ................................................................ Option
Chamber lock ....................................................................... Hooks
Chain lubrication .................................................................. Automatic
Roller bearing lubrication, standard ..................................... 5 nipple banks
Roller bearing lubrication, optional ....................................... 6 nipple banks
Binding ........................................................................................ Net
Prestretcher
Film width ............................................................................. 750mm
Nominal pre-stretch .............................................................. approx. 70%
Max. pre-stretcher ring speed .............................................. approx. 50 revs/min
No. of film layers .................................................................. 2+2+...
Operating system ........................................................................ Programmable controls
Technical specifications
