f. Reinstall bowl and bowl guard assembly and
rotate bowl guard clockwise to securely lock
in place. Align arrow on bowl guard with
arrow on lubricator body.
Occasionally, liquid water will get trapped in the
lubricator bowl. Since water is denser than oil,
the water will migrate to the bottom of the bowl.
Periodically clean bowl to remove the liquid
water.
ADDING OIL
: Use clean oil, preferably SAE 10 or
lighter. Do not use phosphate ester or diestor
based fluids in lubricators.
The lubricator can be filled under pressure by
removing the fill-plug slowly, allowing the pres-
sure in the bowl to vent to atmosphere. After the
pressure is bled off, the fill plug may be removed
completely and oil poured into the fill port. When
the fill plug is removed, a small amount of air will
be venting from the fill port. This is to serve as
an audible signal denoting that the unit is in fact
under pressure. If faster filling is desired, slowly
remove the fill plug to vent the bowl pressure to
atmosphere. Then remove the bowl and bowl
guard assembly by turning counterclockwise. Fill
the bowl, reposition the bowl o-ring seal and rein-
stall the bowl into the body and turn clockwise to
securely lock in place. Reinstall the fill plug. The
unit is ready for use.
ADJUSTING DELIVER
Y RATE: The oil delivery
rate will change automatically to deliver more oil
during increase airflow demand and less oil for
airflow lower than the original setting. To adjust
and set oil delivery rate, the unit must be pressur-
ized and flowing air. Turn the transparent sight
dome counter-clockwise to initiate/increase oil
delivery. Turn the sight dome clockwise to
decrease/stop oil delivery.
If the oil delivery rate should drop, the lubricator
should be inspected and cleaned to remove con-
taminates.
Electronic Timer
The electronic timer has been designed to offer
accurate time measurement over a long period
provided the following cautionary steps are main-
tained,
• It should not be used in environments, which
are very hot or humid.
• Do not use abrasive or corrosive substances
to clean.
• It should not be dropped or shaken vigorously.
FACTORY SERVICE
Should your Multi-Finger Scratch / Mar Tester
require repair or adjustment, carefully pack it in a
rugged container with plenty of cushioning mate-
rial. After obtaining a return authorization num-
ber from the factory, the unit should be shipped,
transportation charges prepaid, to:
TABER Industries
455 Bryant Street
North Tonawanda, New York 14120
USA
7 710 Operating Instructions ver 1.1
