Tack life PMS03 - Accessories; Machine Components

- EN -
3. Accessories
This CROSSCUT AND MITRE SAW WITH DRAG
FUNCTION is supplied with the following accessories:
●
Saw blade with 40 teeth (fitted)
●
Chip bag
●
Clamping device
●
Side support (2x)
●
Hexagonal wrench
4. Machine components (A1-4)
1.
Laser
2.
ON/OFF switch for the laser light
3.
Laser cover
4.
Laser adjustment
5.
Sawing arm
6.
Release knob
7.
Control lever
8.
Carry handle
9.
Top safety hood (fixed)
10.
1Clamping device
11.
Lock for clamping device
12.
Moving safety hood
13.
Safety hood control arm
14.
Cover for saw blade screws
15.
Chip bag
16.
Vertical angle lock
17.
Vertical angle scale
18.
Fence
19.
Hexagonal wrench
20.
Mitre bench
21.
Mitre scale
22.
Bench insert (slotted plate)
23.
ON/OFF switch for machine
24.
Mitre angle lock
25.
Spindle locking button
26.
Connection for dust extractor
27.
Guide rails
28.
Drag lock
29.
Setting screw for cutting depth
30.
Depth stop
31.
Lock nut
32.
Setting screw for sawing head angle
33.
Stopper for 90° lock
34.
Release lever for saw blade guard
35.
Side supports (2x)
36.
Positioning holes for side supports (2 pairs)
- 08 -
