NOMENCLATURES
Ordering Numbers
Part No.
Part Name
HR3
HRF3
HR4
HRF4
1.
Body
1 HR3 (a)
1 HR3 (a)
1HR4(a)
1HR4(a)
2.
Pin for Body
2 HR3 (a)
2 HR3 (a)
2HR4(a)
2HR4(a)
3.
Cup Nut
3 HR3
3 HR3
3HR4
3HR4
4.
Pin for Cup Nut
4 HR3
4 HR3
4HR4
4HR4
5.
Grub Screw
5 HR3
5 HR3
5HR4
5HR4
6.
Lockring for Cup Nut
6 HR3
6 HR3
6HR4
6HR4
7.
Washer for Cup Nut
7 HR3
7 HR3
7HR4
7HR4
7A.
Washer for Cup Nut
7 AHR3
7 AHR3
7AHR4
7AHR4
8.
Thrust Bearing
8 HR3
8 HR3
8HR4
8HR4
9.
Pressure Spring Outer
9 HR3 (9 Nos.)
9 HR3 (9 Nos.)
9HR4(6Nos)
9HR4(6Nos)
10.
Pressure Spring Inner
10 HR3 (9 Nos.)
10 HR3 (9 Nos.)
10HR4(6Nos)
10HR4(6Nos)
11.
Pressure Plate
11 HR3
11 HR3
11HR4
11HR4
12.
Clutch Driver
12 HR3
12 HR3
12HR4
12HR4
12.A
Lockring for Clutch Driver
12 AHR3
12 AHR3
12AHR4
12AHR4
13.
Forward Driver
13 HR3©
13 HR3©
13HR4©
13HR4©
14.
Balls for Forward Driver
14 HR3(6Nos)
14 HR3(6Nos)
14HR4(6Nos)
14HR4(6Nos)
15.
Ball Bearing for Forward
Driver
15 HR3© 15 HR3© 15HR4© 15HR4©
16.
Circlip for Body
16 HR3(2Nos)
16 HR3(2Nos)
16HR4(2Nos)
16HR4(2Nos)
17.
Spacer
17 HR3
17 HR3
17HR4
17HR4
18.
Gear Ring
18 HR3
18 HR3
18HR4
18HR4
19.
Key for Gear Ring
19 HR3
19 HR3
19HR4
19HR4
20. Pinion 20 HR3 (b) 3 Nos.
20 HR3 (b) 3
Nos.
20HR4(b)3Nos 20HR4(b)3Nos
21.
Pin for Pinion
21 HR3 (b) 3 Nos.
21 HR3 (b) 3 Nos.
21HR4(b)3Nos
21HR4(b)3Nos
22.
Reverse Gear
22 HR3
22 HR3
22HR4
22HR4
23.
Spring for Reverse Gear
23 HR3
23 HR3
23HR4
23HR4
24.
Carrier
24 HR3 (b)
24 HR3 (b)
24HR4(b)
24HR4(b)
24 A
Ring for Carrier
24 AHR3 (b)
24 AHR3 (b)
24AHR4(b)
24AHR4(b)
24 B
Bush for Carrier
24 BHR3 (b)
24 BHR3 (b)
24BHR4(b)
24BHR4(b)
24 C
Spacer for Carrier
24 CHR3 (b)
24CHR3 (b)
-
-
25.
Washer for Carrier
25 HR3 (b)
25 HR3 (b)
25HR4 (b)
25HR4 (b)
26.
Ball Bearing for Carrier
26 HR3 (b)
26 HR3(b)
26HR4 (b)
26HR4 (b)
27.
Circlip for Carrier
27 HR3 (2 Nos.)
27 HR3 (2 Nos.)
27HR4
27HR4
28.
Spindle
28 HR3
-
28HR4
-
28.A
Pin for Spindle
28 AHR3
-
28AHR4
-
29.
Expansion Spring
29 HR3
29 HR3
29HR4
29HR4
30.
Lockring for Spindle
30 HR3
30 HR3
30HR4
30HR4
31.
Spring for Ball Carrier
31 HR3
31 HR3
31HR4
31HR4
32.
Ball Carrier
32 HR3
32 HR3
32HR4
32HR4
33.
Balls for Ball Carrier
33 HR3 (3Nos)
33 HR3(3Nos)
33HR4(3Nos)
33HR4(3Nos)
34.
Washer for Spindle
34 HR3
34 HR3
34HR4
34HR4
35.
Lockring for Washer
35 HR3
35 HR3
35HR4
35HR4
36.
Stud for Spindle
36 HR3
36 HR3
36HR4
36HR4
37.
Comp. Spring for Stud
37 HR3
37 HR3
37HR4
37HR4
38.
Washer for Stud
38 HR3
38 HR3
38HR4
38HR4
39.
Lockring for Stud
39 HR3
39 HR3
39HR4
39HR4
40.
Thrust Washer
40 HR3
40 HR3
40HR4
40HR4
41.
Chuck Nut
41HR3(d)
-
41HR4(d)
-
41A.
Bush for Chuck Nut
41AHR3 (d)
-
41AHR4(d)
-
41B.
Washer for Chuck Nut
41BHR3 (d)
-
41BHR4(d)
-
42
L–R Nuts
42 HR3
-
42HR4
-
43.
L–R Stud
43 HR3
-
43HR4
-
43A.
E–Type Circlip
43AHR3
-
43AHR4
-
44.
Stop Arm
44 HR3
44 HR3
44HR4
44HR4
45.
Torque Strip
45 HR3(a)
45 HR3(a)
45HR4(a)
45HR4(a)
46.
Collet
S413
-
S613
-
Collet
S453
-
S623
-
47.
Spanner Set
47 HR3
-
47HR4
-
48.
Allen Key
48 HR3
48 HR3
48HR4
48HR4
49.
Arbor
(a)M20x2.50/MT2
49(a)HR3
49(a)HR3
-
-
(b) M20 x 2.50/MT3
49(b) HR3
49(b) HR3
49(b)HR4
49(b)HR4
(c) M20x2.50/MT4
49© HR3
49© HR3
49b©HR4
49©HR4
