7 / 9
S o f t T r i f o l d T o n n e a u C o v e r
C o v e r
*Slide the retainer plates into the side channels on the vehicle bed. (2 per
side, 1 goes in front and 1 in back)
*Attach the clamp bracket to the plate with the included Allen head
bolts
.
*Line the bracket up with the tri-fold cover clamp location once they are
lined up. Secure bracket to the vehicle bed rail.
Nissan/Toyota/Jeep Trucks (with Utility Track channel) only
