Tactix 326600 - Assembly Instructions

3
ASSEMBLY
INSTRUCTIONS
Remove the packaging
Remove the upper 4 pre-installed bolts (M6x12)
from the back panel.
Remove the 16 pre-installed bolts from the
front, back and side panels of the cabinet.
Save these 16 bolts for assembly step 6.
Lift o the base cabinet, exposing the top chest.
Remove the top chest and set aside.
Re-install the bottom plate with the 16 bolts
from step 3.
FRONT
Caution:
2-person lift required.
1
2
3
4
5
6
