PCP-005/015/050/150/500/1000 Rev 1.1

2021/02/03 1/45 Copyright © 2021 by TAEHA CORP. All Rights Reserved

PRO-PUMP SYSTEM

PCP-005/015/050/150/500/1000 Series

Operation Manual

Questions and Answers

M
Martin MonroeAug 7, 2025
What to do if TAEHA PCP-005 Water Pump dispensing is not possible?
- M
  Michael BernardAug 7, 2025
  If dispensing from the TAEHA Water Pump is not possible, consider the following checks: * Verify the air supply in the tank. * Check the controller power supply. * Ensure the solution is present. * Confirm the solution is loaded in the conduit line. * Inspect the connection of the air fitting and the air fitting in the conduit line. * Check for nozzle clogs. * Verify the pump motor is operating.
E
Eric BensonAug 13, 2025
Why is there a change in the dispensing volume of my TAEHA PCP-005 Water Pump?
- J
  julie65Aug 13, 2025
  If you notice a change in the dispensing volume of your TAEHA Water Pump, examine these potential causes: * Check for any changes in the controller's setting value. * Inspect the chamber for any solution solidification. * See if there is any clogging in the needle. * Check for air bubbles in the conduit line and chamber. * Verify the tank air supply pressure hasn't changed. * Check for leaks in the liquid connection fitting.
R
Richard GarciaAug 19, 2025
What to do if TAEHA PCP-005 drive motor does not operate?
- L
  Laura StewartAug 19, 2025
  If the TAEHA Water Pump drive motor isn't operating, you should: * Check the connection of the motor cable. * Check the set value of the controller. * Check the power supply status. * Check if the solution is solidified in the pump chamber.
A
abryantAug 26, 2025
What to do if TAEHA PCP-005 solution leaks out of the pump?
- M
  Monica StoneAug 26, 2025
  If the solution is leaking out of the TAEHA Water Pump, check the following: * Inspect the o-ring between the chamber and seal block for damage. * Check the abrasion status of the rotary seal in the seal block.
D
Diana MooreAug 31, 2025
What to do if TAEHA PCP-005 makes an abnormal noise?
- R
  ryankirbyAug 31, 2025
  If an abnormal noise occurs while the TAEHA Water Pump is operating, you should: * Check if the bearing in the bearing block has been damaged. * Check the abrasion status of the rotary seal in the seal block. * Check the condition of the motor reducer.

Summary

General Information

About This Manual

Provides essential information for operating the equipment and recommends thorough understanding.

Product Warranty Details

Details warranty period (one year) and cases where it is voided.

Technical Support Contact

Information on how to contact Taeha Corp. for technical support services.

Pro Pump System Features

Pro Pump System Overview

Describes the Pro Pump system as a precise, high-performance dispenser with eccentric screw structure.

Key System Capabilities

Lists key features like consistent dispensing, suck-back function, and easy maintenance.

Pro Pump Specifications

Technical specifications for the Pro Pump models, including dimensions and performance.

Controller Specifications

Technical specifications for the Pro Pump Controller (Procon-100).

Standard System Setup

Describes the standard system where material suppliers are separated from the Pro-Pump.

Module Type System Setup

Describes the module type system where the material supplier is integral with the Pro-Pump unit.

Component Identification

Pro Pump Part Breakdown

Diagram illustrating and labeling the main components of the Pro Pump.

Operation and Setup

Assembly and Bubble Removal

Instructions for connecting rotor/stator and eliminating air bubbles before dispensing.

Getting Started Guide

Steps for connecting the system, powering on, setting pressure, and preparing the pump.

Disassembly Procedures

Disassembling PCP-005;015;050

Step-by-step guide for disassembling PCP-005/015/050 models for maintenance.

Disassembling PCP-150;500

Step-by-step guide for disassembling PCP-150/500 models for maintenance.

Disassembling PCP-1000

Step-by-step guide for disassembling PCP-1000 model for maintenance.

Pro Pump Part Lists

PCP-005 Parts List

Detailed list of parts for the PCP-005 model with diagram and part numbers.

PCP-015 Parts List

Detailed list of parts for the PCP-015 model with diagram and part numbers.

PCP-050 Parts List

Detailed list of parts for the PCP-050 model with diagram and part numbers.

PCP-150 Parts List

Detailed list of parts for the PCP-150 model with diagram and part numbers.

PCP-500 Parts List

Detailed list of parts for the PCP-500 model with diagram and part numbers.

PCP-1000 Parts List

Detailed list of parts for the PCP-1000 model with diagram and part numbers.

Maintenance and Troubleshooting

Alarm Notifications and Actions

Explains how the system displays alarms and the actions to take for each.

Regular Inspection Guide

Details periodic and occasional inspection procedures for different aspects of the equipment.

Troubleshooting Common Issues

Provides a table of common troubles with their possible causes and corrections.

TAEHA PCP-005 Series Specifications

General

Model	PCP-005 Series
Power Source	Electric
Voltage	220V
Frequency	50/60 Hz
Category	Water Pump
Outlet Diameter	25 mm
