TAG Player System - HUD* (HEADS up DISPLAY) UNIT Illustration

HUD (HEADS UP DISPLAY)
Flashes when you are tagged by
another player.
Flashes when your TAGGER is
aimed directly at another player.
Flashes when you tag another
player.
VISUAL CONFIRMATION SYMBOLS:
1. Alert Icons (Tagged, Locked-On, Scored, Danger)
2. Alpha-Numeric Display (Instruction, Game Type, Time, Warnings)
3. Multipurpose Bar Graphs (Ammo, Tags)
4. Reconfigurable Numeric Display (Team, Player, Ammo,
Shields, Tags)
1 2
3 34
6
Adjustable strap
Eyepiece
[visual feedback]
Earpiece
[audio feedback]
Optical Projector
Connector
Red
Yellow
Green
