Tailfin AeroPack - Orientate Arch and Fast Release Dropouts; Use Tailfin Logo for Arch Orientation; Position Dropout on Arch; Set Quick Release Pin Direction

Orientate Arch and Fast
Release Dropouts
Step One
A
B
C
Use the Tailfin logo to
orientate the Arch.
Place Dropout on Arch.
The sloped side of the
dropout faces outside
The quick release pin
faces backwards
A
C
D
*Not applicable to Direct Mount setup, proceed to Step 3
D
The logo is legible when
stood behind the bike. This
will ensure panniers are
also at the correct angle
B
