09/01 IPN: M5000-00-102
Spares kits D - 17
Table D-2: Orca 5010/5030 spares kit (TOPA-SP-401)
IPN Description Quantity Reference
040-05500-08 Volume Control Switch 10 D-8 (3), D-9 (3)
219-50029-00 RF out assembly 5 D-11 (1)
220-01414-03 Aux Flex Connector PCB 5 D-10 (1)
231-00010-45 Channel Selector Switch 10 D-8 (2), D-9 (2)
232-00010-42 Switch PTT (Low Profile) 5 D-8 (8), D-9 (6)
240-02156-01 Antenna SMA Connector 10 D-12 (4)
252-00010-77 Speaker 40mm 0.5W 16E FST 5 —
252-00010-56 Microphone 5 D-8 (11)
316-85133-00 PTT/Function Key Retaining Plate 10 —
360-02019-00 Microphone Grommet/Seal 10 D-5 (1)
303-11213-00 Handportable Chassis 5 D-4 (2), D-5 (3)
303-30072-00 Battery Catch 20 —
308-01057-02 Housing Accessory Dummy Cover 20 —
311-01049-00 Channel Selector Knob 20 D-2 (1)
311-03108-00 PTT/Function Keypad 20 —
316-06765-00 Rear Panel 5 D-10 (7)
316-06763-00 Knob Label 5 D-2 (3)
365-01673-00 Insert Front Panel Logo Label 1 —
319-01026-00 Main RF Shield 5 D-4 (1)
345-00020-09 PA Screw M2x5mm Pan Torx 10 D-8 (10)
345-00020-11 Chassis Screw M2x8mm Pan Torx 10 D-1 (3)
349-00030-00 Speaker Screw 1.8x5mm Torx 10 D-7 (3)
352-00010-52 Channel/volume Control Nut (M6x7.9x3mm) 20 D-12 (9)
352-01053-00 Antenna SMA Connector Nut 10 D-12 (8)
353-00010-42 Ribbed Lock Washer M6x10x0.7mm 30 D-12 (7)
356-01077-00 Battery Contact Probe 10 D-9 (7)
360-01060-00 PTT/Function Key Actuator 40 —
360-00010-39 Chassis Plug Seal 10 D-10 (9)
362-01087-00 Battery Contact Seal 10 D-9 (8)
362-01106-00 Rear Panel Seal 10 D-10 (5)
362--01089-01 Aux Flex Seal 10 D-10 (2)
362-01091-01 Knob Seal 10 D-12 (10)
362-01092-02 Main Seal 20 —
369-01039-00 Adhesive Ring 40mm (speaker) 5 D-7 (2)
OPP401 Front Panel Assembly. This comprises the following parts: 1 —
252-00010-77 Speaker 40mm 0.5W 16E FST 1 —
307-01022-00 Speaker cloth 1 —
316-06760-00 Front Panel 1 —
316-06763-00 Knob Label 1 D-2 (3)
354-01044-00 Bush M2 Threaded Brass 2 —
369-01039-00 Adhesive Ring 40mm (speaker) 1 D-7 (2)
