Tait Orca 5020 - Orca 5010;5030 Re-Skinning Kit (TOPA-SP-404)

D - 20 Spares kits
09/01 IPN: M5000-00-102
Table D-5: Orca 5010/5030 Re-skinning kit (TOPA-SP-404)
Table D-6: Orca 5035 Re-skinning kit (TOPA-SP-405)
Table D-7: Orca 5020/5040 Re-skinning kit (TOPA-SP-406)
Table D-8: Orca 5020/5035/5040 User Interface PCB and Shield (TOPA-SP-407)
IPN Description Quantity
311-01049-00 Channel Knob Gr 1
311-01050-00 Volume Knob Gr 1
311-03108-00 PTT/Function Keypad 1
316-06765-00 Rear Panel 1
316-85133-00 PTT/Function keypad retainer plate 1
345-00020-11 Screw M2x8mm SS Pan Torx Patch 2
360-01060-00 Actuator Pressel 2
362-01106-00 Rear Cover Seal 1
362-01091-01 Knob Seal 1
362-01092-02 Main Seal 1
OPP401 PHA Front Panel Assembly 1
IPN Description Quantity
311-01049-00 Channel Knob Gr 1
311-01050-00 Volume Knob Gr 1
311-03108-00 PTT/Function Keypad 1
316-06765-00 Rear Panel 1
316-85133-00 PTT/Function keypad retainer plate 1
345-00020-11 Screw M2x8mm SS Pan Torx Patch 2
360-01060-00 Actuator Pressel 2
362-01106-00 Rear Cover Seal 1
362-01091-01 Knob Seal 1
362-01092-02 Main Seal 1
OPP501 PHA Front Panel Assembly 1
IPN Description Quantity
311-01049-00 Channel Knob Gr 1
311-01050-00 Volume Knob Gr 1
311-03108-00 PTT/Function Keypad 1
316-06765-00 Rear Panel 1
316-85133-00 PTT/Function keypad retainer plate 1
345-00020-11 Screw M2x8mm SS Pan Torx Patch 2
360-01060-00 Actuator Pressel 2
362-01106-00 Rear Cover Seal 1
362-01091-01 Knob Seal 1
362-01092-02 Main Seal 1
OPP601 PHA Front Panel Assembly 1
IPN Description Quantity
OPF200-B UI PCB SMT Subassembly 1
311-04005-00 Ins Poly Dome for 5020/5040 1
319-01026-00 Main Shield RF 1
399-00010-86 Static Shielding Bag 127x203mm 1
008-36671-80 LCD Display 12x2 Lines Flex 1
304-07043-00 LCD Frame Holder 1
220-01501-00 PCB Flexi User Interface 1
