96 Troubleshooting
GPS info Displays the antenna connection state (Connected
or Not Connected), GPS fix status (valid or No Fix),
number of satellites, horizontal d of precision
(HDOP), time and date of last fix, and any number of
NMEA errors since the radio was switched on.
GPS NMEA
data
Displays the last raw data received from a GPS
antenna/receiver connected to the radio. The radio
will display all supported sentence formats received
(for example $GPRMC and $GPGGA sentences).
Note that the display will not automatically refresh
when new data is received.
Keypad test Sounds an audible tone when a key is pressed or
released on the radio. The radio also displays the
key name along with “pressed” or “released”.
Operating time Displays the overall operating time, high-power
transmission time and low-power transmission time.
Use the scroll keys to scroll though the times.
QoS Displays information about the quality of service
(received signal strength (RSSI) with an indication of
digital voice quality).
RSSI Displays the received signal strength (RSSI) of the
current channel.
Rx 1011 Receives a 1011 Hz tone and displays the received
signal strength (RSSI) and the bit error rate (BER) of
the received signal.
Site display Shows the channel number, signal strength and
system-identity code (SYSCODE) for the currently
registered trunk site.
Site measure Lists the current trunk site (indicated with an
asterisk) and up to six detected adjacent sites, with
received signal strength (RSSI) information.
Supply voltage Display shows the supply voltage. While the supply
voltage is displayed, the voltage reading is updated.
Tone test Generates an audible tone for the duration of the
test.
Tx 1011 Transmits a tone of 1011 Hz on the current P25
channel.
Tx 1011 Cal Transmits a 1011 Hz tone on the current channel
with a bit error rate (BER) of 5%.
Test Description
