T2004 Multi-Control Head System Manual System Overview 17
© Tait Electronics Limited May 2004
A speaker and microphone are not provided as part of the Primary Multi-
Control Head Kit, as the Primary control head uses the speaker and
microphone already supplied with the radio.
T2004-A21 and T2004-A41 Secondary Multi-Control Head Kit Parts
The T2004-A21 or T2004-A41 Secondary Multi-Control Head Kit parts
are listed below:
This kit provides one Secondary control head and other equipment needed
to install the control head for use with the radio. Between one and four
Secondary Multi-Control Head Kits can be installed as part of your system.
Each control head can be installed anywhere on a multi-drop line up to
2000M long, and is powered locally by a mains-operated DC plug pack. A
speaker plugs into each control head to provide local Rx audio and Tx audio
from other control heads in the system.
Qty IPN Description
1 X2H222 or X2H242 T2020 or T2040 Secondary Control Head
a
a. For more information about the X2H222 or X2H242 Secondary Control Head, see
Part B of this manual.
1 219-02900-00 Micromatch to RJ45 cable
1 240-04051-00 RJ45 Screw Terminal Wallbox
2 349-00010-33 Screw, #6*3/4: S/T P/P (bracket to wall)
1 005-00000-40 T2000 Speaker Kit (incl. mount)
1 252-00010-76 T2000 microphone
1 219-02907-00 Power/ Speaker cable (no plug pack)
1 M2004-00-000-315 Installation manual
1 252-00010-49 Microphone clip
1 302-05211-00 Head mounting bracket
2 350-01007-00 Head thumb screws
