Tait T2004 User Manual

48 X2H2xx PCB Information T2004 Multi-Control Head System Manual
May 2004 © Tait Electronics Limited
R26 036-15100-10 Res M/F SMD 0805 10k 1%
R28 036-10000-00 Res M/F SMD 0805 0e 0.125w
R34 036-14470-10 Res M/F SMD 0805 4k7 1%
R35 036-14470-10 Res M/F SMD 0805 4k7 1%
R42 036-15470-10 Res M/F SMD 0805 47k 1%
R43 036-15470-10 Res M/F SMD 0805 47k 1%
R44 036-15470-10 Res M/F SMD 0805 47k 1%
R53 036-15470-10 Res M/F SMD 0805 47k 1%
R69 036-15470-10 Res M/F SMD 0805 47k 1%
R79 036-15470-10 Res M/F SMD 0805 47k 1%
R80 036-15100-10 Res M/F SMD 0805 10k 1%
R81 036-15100-10 Res M/F SMD 0805 10k 1%
R82 036-15100-10 Res M/F SMD 0805 10k 1%
R83 036-15100-10 Res M/F SMD 0805 10k 1%
R84 036-13560-00 Res M/F SMD 0805 560e 5%
R85 036-13560-00 Res M/F SMD 0805 560e 5%
R86 036-13560-00 Res M/F SMD 0805 560e 5%
R87 036-13560-00 Res M/F SMD 0805 560e 5%
R88 036-16180-00 Res M/F SMD 0805 180k 5%
R89 036-13470-00 Res M/F SMD 0805 470e 5%
R90 036-15100-10 Res M/F SMD 0805 10k 1%
R91 036-14120-00 Res M/F SMD 0805 1k2 5%
R92 036-14270-00 Res M/F SMD 0805 2k7 5%
R93 036-14100-00 Res M/F SMD 0805 1k 5%
R94 036-14270-00 Res M/F SMD 0805 2k7 5%
R95 036-14120-00 Res M/F SMD 0805 1k2 5%
R96 036-14270-00 Res M/F SMD 0805 2k7 5%
R97 036-13470-00 Res M/F SMD 0805 470e 5%
R98 036-13390-00 Res M/F SMD 0805 390e 5%
R99 036-13470-00 Res M/F SMD 0805 470e 5%
R100 036-14270-00 Res M/F SMD 0805 2k7 5%
R101 036-14270-00 Res M/F SMD 0805 2k7 5%
R102 036-15470-10 Res M/F SMD 0805 47k 1%
R103 036-15100-10 Res M/F SMD 0805 10k 1%
R104 036-18100-00 Res M/F SMD 0805 10m 5%
R105 036-14330-00 Res M/F SMD 0805 3k3 5%
R106 036-15470-10 Res M/F SMD 0805 47k 1%
R107 036-15100-10 Res M/F SMD 0805 10k 1%
R108 036-15100-10 Res M/F SMD 0805 10k 1%
R109 036-15100-10 Res M/F SMD 0805 10k 1%
R110 036-15100-10 Res M/F SMD 0805 10k 1%
R111 036-13560-00 Res M/F SMD 0805 560e 5%
R112 036-13560-00 Res M/F SMD 0805 560e 5%
R113 036-13560-00 Res M/F SMD 0805 560e 5%
R114 036-13560-00 Res M/F SMD 0805 560e 5%
R117 036-13120-00 Res M/F SMD 0805 120e 5%
R119 036-15100-10 Res M/F SMD 0805 10k 1%
R120 036-16150-00 Res M/F SMD 0805 150k 5%
R121 036-14220-00 Res M/F SMD 0805 2k2 5%
R123 036-13470-00 Res M/F SMD 0805 470e 5%
R124 036-13470-00 Res M/F SMD 0805 470e 5%
R125 036-15470-10 Res M/F SMD 0805 47k 1%
R126 036-15470-10 Res M/F SMD 0805 47k 1%
R127 036-14470-10 Res M/F SMD 0805 4k7 1%
R128 036-15270-00 Res M/F SMD 0805 27k 5%
R129 036-15470-10 Res M/F SMD 0805 47k 1%
R130 036-15220-10 Res M/F SMD 0805 22k 1%
R133 036-16270-00 Res M/F SMD 0805 270k 5%
R135 036-13120-00 Res M/F SMD 0805 120e 5%
R136 036-13120-00 Res M/F SMD 0805 120e 5%
R138 036-15100-10 Res M/F SMD 0805 10k 1%
R139 036-15390-00 Res M/F SMD 0805 39k 5%
R140 036-16220-00 Res M/F SMD 0805 220k 5%
R141 036-15270-00 Res M/F SMD 0805 27k 5%
Ref IPN Description
R142 036-15150-10 Res M/F SMD 0805 15k 1%
R143 036-15270-00 Res M/F SMD 0805 27k 5%
R144 036-12390-00 Res M/F SMD 0805 39e 5%
R145 036-15270-00 Res M/F SMD 0805 27k 5%
R146 036-10000-00 Res M/F SMD 0805 0e 0.125w
R147 036-14100-00 Res M/F SMD 0805 1k 5%
R148 036-15100-10 Res M/F SMD 0805 10k 1%
R149 036-15100-10 Res M/F SMD 0805 10k 1%
R595 036-12100-10 Res M/F SMD 0805 10e 1%
RLY2 002-10117-00 IC SMD TS117 Opto 8p Fpak
S10 240-04021-61 Skt 6w Phone Jack S-Ent
S11 240-00020-87 Hdr 2x5w Ra Pcb Mtg
T2 054-00010-20 Xmfr SMD Ct Etal2782
U1 002-10018-77 IC SMD LM1877M Dual Af Pwr Amp
U2 002-10003-58 IC SMD LM358 Dual 0-Amp
U13 240-04020-42 Skt 44 Pin SMD Plcc
U14 002-10340-64 IC SMD MC34064 L-Volt Sense
U15 002-74900-04 IC SMD 74HC04D 6x Inv Buffd
U16 002-74900-04 IC SMD 74HC04D 6x Inv Buffd
U17 002-10085-76 IC SMD PCF8576T LCD Dvr
U19 002-10004-83 IC SP483EEN RS485 Xcvr/Esd S08
U20 002-10016-51 IC SMD SSM2165-1s Preamp S0-8
U21 002-10004-83 IC SP483EEN RS485 Xcvr/Esd S08
U22 002-12951-00 IC SMD LP2951CM Adj Vltge Reg
U23 002-10021-42 IC SMD TLE2142CD Opamp S08
X2 274-01070-00 Xtal 4.000MHz Hc-49u/S Lo-Prof
002-20068-07 IC MC68HC705C8AFN Otp Micro
209-01027-00 Strip A3m2544 SI Impregnated
228-23722-01 Pcb T2020/40 Multi/Ctrl Head
304-07036-02 Light Sprdr 20 Bttn T2K SII
311-01042-01 Knob A3M2530 T2K SII
311-03076-01 K/Pad T2020 SII International
312-01046-05 Lens LCD Dsply T2K FM2/TR2
316-02001-00 Pnl M/Ctrl Hd Back T2K
316-06430-02 Pnl Frt Scrn T2020/40/50 SII
316-85125-00 Plate Cvr T2K
365-01516-01 Lbl T2K Model Id T/A
399-00010-53 Bag Plstc 150*250mm
349-00010-22 Scrw 4-20x3/8 P/P Trilobe-P BZ
352-00010-17 Nut M4 Pressed Sq S/T Bz
349-00010-24 Scrw 4-20x5/8 P/P Trilobe-P BZ
Ref IPN Description
