Takeuchi TB210R - Page 15

SERVICE DATA
DIMENSIONAL DRAWING
2
2
DIMENSIONAL DRAWING 2A0BL00
H
2
: With the crawler extended
R
2
: Side plate attached
Unit: mm (in.)
Rubber crawler
A 2955 (116.3)
B 750 (29.5)
C 2190 (86.2)
D 610 (24.0)
E 395 (15.6)
F 1005 (39.6)
G 1325 (52.2)
H 750 (29.5)
H
2
1020 (40.2)
J 180 (7.1)
K 160 (6.3)
L 1320 (52.0)
M 980 (38.6)
P 505 (19.9)
Q 510 (20.1)
R 750 (29.5)
R
2
1020 (40.2)
S 200 (7.9)
T 2245 (88.5)
U 930 (36.6)
V 85°
W 85°
X 3415 (134.4)
Y 1475 (58.1)
