Takeuchi TB210R Workshop Manual

SERVICE DATA
SPECIFICATION TABLES
1
2
SPECIFICATION TABLES 2B0BL00
SPECIFICATION TABLES
Performance
*: At the operator location as stipulated by ISO 6396: 2008.
Dimensions of completed machine
Dimensions of base machine
Operating mass
Rubber
crawler
Canopy kg (lb) 1150 (2535)
Cab kg (lb) –
Steel
crawler
Canopy kg (lb) –
Cab kg (lb) –
Rated output
Net (ISO 14396) kW/min
-1
(hp/rpm) 8.8 (11.8) /2200 (2200)
Net (ISO 9249/SAEJ 1349) kW/min
-1
(hp/rpm) 8.7 (11.7) /2200 (2200)
Bucket capacity
Heaped capacity m
3
(ft.
3
) 0.022 (0.76)
Struck capacity m
3
(ft.
3
) 0.016 (0.57)
Standard loading mass kg (lb) 30 (64)
Slew speed min
-1
(rpm) 10 (10)
Travel speed
Rubber
crawler
1st km/h (mph) 2.0 (1.24)
2nd km/h (mph) 3.7 (2.3)
Steel
crawler
1st km/h (mph) –
2nd km/h (mph) –
Maximum tractive force kN (lbf) 12.8 (2880)
Gradeability
%58
deg. 30
Ground pressure
Rubber
crawler
Canopy kPa (psi) 28 (4.06)
Cab kPa (psi) –
Steel
crawler
Canopy kPa (psi) –
Cab kPa (psi) –
Noise level
Sound-power level dB (A) 91
Sound-pressure
level*
dB (A) –
Overall length
Standard arm mm (in.) –
Middle arm mm (in.) –
Long arm mm (in.) 2955 (116.3)
Overall width
During normal operation mm (in.) 1020 (40.2)
Track retracted mm (in.) 750 (29.5)
Overall height
Rubber
crawler
Canopy mm (in.) 2190 (86.2)
Cab mm (in.) –
Steel
crawler
Canopy mm (in.) –
Cab mm (in.) –
Overall length of base machine mm (in.) 1230 (48.4)
Overall width of base ma-
chine
During normal operation mm (in.) 1020 (40.2)
Track retracted mm (in.) 750 (29.5)
Upper structure overall width mm (in.) 750 (29.5)
Upper structure overall
width
Left mm (in.) 375 (14.8)
Right mm (in.) 375 (14.8)
Cab overall width mm (in.) –
