Thermostat Thermostat with cover removed Main Fan
Main Fan
Description
The main fan is situated at the rear of the appliance and is activated by the thermostat.
Operation
The fan has two main functions, firstly to distribute the hot air and secondly to cool the
heat exchange to avoid overheating.
THE APPLIANCE CANNOT BE USED IF THE MAIN FAN IS NOT OPERATIONAL
If this were to occur then the heat exchange would not be able to get rid of the excess
heat built up and damage to the steel work would occur.
Maintenance
Frequent inspection should be made to the belt tension during the first 48 hours of
operation and again after the first 2 months of usage this only applies to the belt drive
versions. Smaller units have a direct drive Main Fan. General Inspection of the fan
should not be more then three monthly intervals.
Daily Checks
Before lighting
- Check the operation of the Combustion Fan. It is vital that the combustion fan
is operational whenever the appliance is used.
- Check the Main Fan is operational by pressing in the Thermostat manual
button.
- Within the Firebox -
● Ensure brickwork and roofing tiles are intact
● Ensure top tube is not warped and undamaged*
● Ensure grates are unblocked and ash pan is clear
*Excluding the T75 model
