Talley QUATTRO PLUS - Fault Finding - Additional Issues; Pump or Triac Faults; Uncalibrated System Faults

If fault persists,
power unit requires
inspection.
Reconnect to power
supply to continue
using mattress.
PUMP or
TRIAC
FAULT
AC FAIL
FAULT
LOW
PRESSURE
FAULT
Indicates mains
power failure. Silence
sounder by
pressing
MUTE button.
Check air supply hose
is correctly attached
to power unit (i.e.
mattress hose
connector is correctly
aligned with power
unit connector and is
fully rotated clockwise
so green indicator fills
window on power unit
connector).
If fault persists,
power unit requires
inspection.
Reset power unit by
pressing
MUTE button.
ROTOR
SYSTEM
FAULT
If fault persists,
system requires
inspection.
Reset power unit by
pressing
MUTE button.
Reset power unit by
pressing
MUTE button.
EMI
FAULT
Caused by external
RF fields. Fault will
clear when
interference ceases.
Check air cells and
tubing are intact.
FAULT
Reset power unit by
pressing
MUTE button.
MATTRESS
FLAT
(no sounder)
Check that mains
power is connected,
indicated by
illuminated LCD
display, and allow at
least 20 minutes for
mattress to inflate.
UNCALIBRATED
The system will
continue to operate
but contact Talley for
recalibration as soon
as possible.
Check that CPR
device (if applicable)
is fully closed,
i.e. dial of CPR device
is rotated clockwise
until clicked into
closed position.
13
OTHER FAULTS
PUMP OR TRIAC fault - indicates a pump control failure or an open pump coil fault. Should
this occur, contact Talley.
UNCALIBRATED - contact Talley for recalibration.
If you have any queries relating to this system please contact Talley or your local authorised
dealer.
