TRANSPORTATION OF MATTRESS SYSTEM
The mattress should be transported at and not rolled. Mattresses should not be stored more
than 6 high as this can potentially be a safety hazard when handling. To protect the covers,
mattresses should be packed in minimum 200 micron clear polythene.
Specifications
ALTERNATING AIR PRESSURE POWER UNITS (Medical Device Classification: Class IIa)
Model Ref.: Type 19
Construction: ABS Plastic
Dimensions: 335mm/13.2” x 233mm/9.2” x 165mm/6.5”
Weight: 3.4 kg / 7.5 lbs
Mains Cable: 5 metres / 16.5’
For the USA:- only a hospital grade attachment plug with a 15A
NEMAP 5-15 configuration and 18AWG hospital grade flexible cord is
to be used, as supplied by Talley.
Electricity Supply: 230V
~
50Hz (CE marked)
120V
~
60Hz (cETLus listed)
230V
~
60Hz
Rated Input: 9.4 VA
Fuse Rating: T500mA 250V HRC (ceramic) 5 x 20 mm
IP Rating: IP21
Cycle Time: QUATTRO
®
ACUTE: variable (continuous)
QUATTRO
®
PLUS: 16 minutes (continuous)
QUATTRO
®
OVERLAY: 16 minutes (continuous)
PULSAIR
®
CHOICE: 16 minutes (mattress replacement) / 8 minutes
(mattress overlay/cushion) (continuous)
ALTERNATING AIR PRESSURE MATTRESSES (Medical Device Classification: Class IIa)
Construction: BASE: QUATTRO
®
ACUTE
/
QUATTRO
®
PLUS
/
QUATTRO
®
OVERLAY
:
Woven nylon 940 DTEX PU coated both sides
PULSAIR
®
CHOICE
:
PVC coated 2oz nylon, 350 micron
CELLS: PU film COVER: PU coated stretch nylon 255g/m
2
Options: Standard / Long / Narrow
Type: QUATTRO
®
ACUTE
/
QUATTRO
®
PLUS
/
PULSAIR
®
CHOICE MATTRESS
REPLACEMENT: Orthodifferential TISSUEgard
™
pleated air cells
operating in a 1-in-4 alternating air pressure cycle
QUATTRO
®
OVERLAY: Orthodifferential air cells operating in a 1-in-4
alternating air pressure cycle
PULSAIR
®
CHOICE mattress overlay: Orthodifferential air cells
operating in a 1-in-2 alternating air pressure cycle
Dimensions QUATTRO
®
ACUTE: 1980mm x 900mm x 240mm (PAEDIATRIC version:
1300mm x 650mm x 180mm)
(UK standard size - approx.
max. top surface, inflated
+
/- 15mm
