Lower hull
1
Copyright 2017 www.35rctank.com Page 2
make round holes with a circular file
lower hull
lower hull inside
to make room for torsion bars, remove 0.5mm
4mm
remove
A3
remove
4mm
make slot for sprocket
set screw
2
Torsion bars
torsion bar mount (L)
4.5mm spacer
4.5mm spacer
torsion bar mount (R)
4.5mm spacer
