Lower hull connections
micro receiver
Spektrum 2.4G
AR6110e
1 Cell 3.7V Lipo battery
carboard
Copyright 2017 www.35rctank.com Page 8
16
Using Lipo battery
2) Make sure battery is small enough to put inside the lower hull.
3) Solder connector for MTC-2 as shown. Keep original connector for charging.
safety precautions and always use a dedicated Lipo charger.
Lipo battery can be dangerous if not use properly! Follow all
MTC-2 power connector
MTC-2 will damage if polarity is not correct!
1) Use 3.7V/1Cell Lipo battery (300-1000mAh)
3
.
7
V
/
1
Cell
L
i
p
o
3
0
0-10
0
0m
A
h
solder and wrap with
heat shrink tubing
+
-
(300 - 1000mAh)
secure cable with
adhesive tape
15
Main gun search light
press fit to C15
do not apply cement
remove
search light mount
