Page 2
ECS-3301/B
CRANKCASE / FLYWHEEL • FIGURE 2
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
2-19 0710406321 SHIM,CRANKSHAFT,0.1 V
2-19 0710406323 SHIM,CRANKSHAFT,0.2 V
2-19 0710406324 SHIM,CRANKSHAFT,0.3 V
2-19 0710406325 SHIM,CRANKSHAFT,0.4 V
2-21 06600000200 NUT,FLYWHEEL 1
2-22 99210070012 WASHER,S,7 1
2-23 99201070011 WASHER,7 1
2-24 1552152991 ROTOR,MAGNETO 1 ~S039107
2-24 1552154090 ROTOR,MAGNETO 1 S039108~
2-26 7880174020 PAWL,STARTER 2
2-27 7900174020 SPRING,STARTER PAWL 2
2-28 99355040001 RING,STOP 2
2-36 99461050204 BOLT,HEX,HOLE,5X20,S 4
2-41 0720174093 CRANKCASE,ASS'Y 1 ~C110350 - Incl brgs, seals and gasket
2-41 0720174094 CRANKCASE,ASS'Y 2 C110351~ Incl brgs, seals and gasket
2-42 99966122240 SEAL,OIL,#12227 2
2-43 0900174021 GASKET,CRANKCASE 1 ~Y211450
2-43 0900174120 GASKET,CRANKCASE 1 Y211451 to C110350
2-43 0900174G20 GASKET,CRANKCASE 2 C110351~
2-44 99961620106 BEARING,BALL,#6201 2
2-46 99905250980 ROLLER,NEEDLE,2.5X9.8 1
